Otolaryngology Ear Suction Instruments Ear Suction

Model NO.: MC-ENT-3202-DM
Tray: Stainless Steel
CCD Camera: 540TV/Line
Liquid Medicine Bottle: Glasses
X-ray Viewer: X Ray Screen
Work Humidity: Less Than 8o%
Trademark: MeCan
Specification: CE FDA
Origin: Guangzhou China
HS Code: 90189030
Model NO.: MC-ENT-3202-DM
Tray: Stainless Steel
CCD Camera: 540TV/Line
Liquid Medicine Bottle: Glasses
X-ray Viewer: X Ray Screen
Work Humidity: Less Than 8o%
Trademark: MeCan
Specification: CE FDA
Origin: Guangzhou China
HS Code: 90189030
Otolaryngology Ear Suction Instruments Ear Suction
Model: MC-ENT-3202-DM (Completed Set)

Normal running conditions:
1. Temperature of Environment: 10ºC~45ºC
2. Relative Humidity≤80%
3. High Atmospheric Pressure: 86~106 kPa
4. Power: 230±10VAC, 50-60Hz, 1000VA

Technical Parameter:
1) Spray rod, positive pressure of blow device:
             0.1Mpa-0.15Mpa; (Adjusting)
2) Negative pressure of suction lube:
             ≥0.07Mpa; (Adjusting)
3) Suction vacuum pump: 370W;
     000CC main suction apparatus 1pc
4) Compressor pump: 80W   1 pc
5) Power: 230±10VAC, 50-60Hz, 1000VA
6) Preheated anti-fog apparatus: 300W

Configuration:
No Name Quantity  Remark
1 Mainframe 1pc Marble board
2 Sprayer Curved 1pc
Straight 2pcs
Copper
3 Suction device 1pc Copper
4 Waste bottle 1pc 2500cc
5 Projection lamp & balance arm 1pc≥50W (illuminate≥1*104 LUX
6 tray 2pcs Stainless steel
7 Cotton jar 4pcs Stainless steel
8 Anti fog heater 1set
9 Liquid medicine bottle 6pcs Glasses
10 Endoscope 2pcs Sinoscope & Laryngoscope
11 CCD camera 1 set 540TV/line
12 Cold light source 1 set Xenon light 250W
13 Computer 1 set With English software,
14 Foot captor 1 pc For PC
15 LCD Display 2 sets 19'' LCD
16 Medical Monitor 1 set LCD 17' Samsung
17 Color printer 1set HP
18 X-ray viewer 1set X ray screen
19 Microscope 1 set Microscope
20 Patient Chair 1 set Patient Chair


CCD Camera


TECHENICAL PARAMETERS for CCD Camera:
Item CCD camera PK-100
Camera 1/3''D
Pelx H×V NTSC: 768H×494V   410,000
PAL:  752H×582V   440,000
Horizontal definition 580TV lines
Electronic Shutter NTSC:  1/60~1/100,000 sec
PAL: 1/50~1/100,000 sec
Minimum illumination 0.5 LUX
Synchronization manner Inner-synchronization
Signal-to-Noise More than 48dB
Plus control Automatic
Video output 1.0Vp-p, 75Ωcomplex signal
Adapter(Either) OES or rigid
Connection Cable 2.5m normal. And special length needs order.
Power AC220+10%
Power Consumption Standard DC12V (±10%), Max. 160mA
Dimension(width" height" depth) 304mm×95mm×310mm
Operating temperature 14 F ~ 122 F (-10 C ~ +50 C)
Storage temperature -4 F ~ 140 F (-20 C ~ +60 C)
Work humidity Less than 8o%
White Balance manual

XENON Cold Light Source 250W (Fiber optic cable 2m)



1. Muti-specifications light.
2. Adjust brighting
3. Stable light output
4. long bulb life.
5. 2000mm fibre cable




TECHENICAL PARAMETERS for XENON Cold Light Source:
1. Voltage of power supply: 220V 50Hz (Fuse: 5A)
2. Input power: 470VA
3. J. equipment type: 1 BF
4. Power of xenon lamp: 250 W
5. Effective luminance of xenon lamp: ≥5800,000LX
6. Xenon lamp color temperature: 5600K
7. Noise: <55dB
8. Chassis temperature:<55ºC
9. Under normal operating temperature of the continuous


Endoscope
Sinuscope, Otoscope, Laryngoscope.
